As our premium entry-level player, the CD5 XS doesn’t just sound better than our CD5si: it also gives you more scope for growth. You can make its sound even more expressive by adding our FlatCap XS power supply component. Alternatively, you can use its transformer-coupled digital output to upgrade it with our external DAC. Add an ND5 XSnetwork player and Naim amplification and you’ll have an accessible high-end separates system capable of delivering a seriously convincing sound no matter how you choose to listen.

Features
Stiff, extruded aluminium casework provides excellent resistance to external vibration
High performance drawer and transport mechanism as with our premium CDX2 model, providing low resonance, low-inertia disc operation
BNC digital output for connection to external DAC
Product Specification
Audio Outputs
Analogue
DIN, RCA

Line Outputs Fixed (level)
2.1V RMS at 1kHz

Load Impedance
10kΩ (min.)

Frequency Response
10Hz – 20kHz, +0.1/-0.5dB

THD + N
<0.1%, 10Hz -18kHz at full level

De-emphasis
±0.1dB referred to main response

Digital Outputs (type)
S/PDIF, 75Ω BNC

Output Impedance
10Ω (max.)

Connectivity
Remote Control
Infra Red (RC5)

Remote Input
1 x rear panel 3.5mm jack (RC5 modulated/unmodulated)

RS232
Optional (DE9 female)

Formats
CD Formats
Red Book

Disc Compatability
CD, CD-R

User Control
Front Panel
Four button matrix

Handheld
Remote handset

Power
Supply Voltage
100V, 115V, 230V; 50 or 60Hz

Power Supply Options
FlatCap, HiCap, SuperCap

Power Consumption
30VA (peak)

Upgrades
Power Supply
FlatCap XS, HiCap, SuperCap

Other
DAC

Physical
Dimensions (HxWxD)
70 x 432 x 301 mm

Weight
6 kg

Supplied with
NARCOM-4 Remote Control, Standard Interconnect, Mains Lead,
